  • Double Shaft Shredder

    The dual-shaft shredder is a powerful machine designed for heavy-duty shredding of a wide range of materials, including plastics, rubber, metals, and electronic waste. It features two parallel shafts with interlocking blades that rotate in opposite directions, ensuring efficient and consistent material breakdown. This equipment is ideal for reducing large volumes of waste into smaller, manageable pieces, promoting recycling, reducing environmental impact, and supporting sustainable waste management in various industries.

HomeHot productDouble Shaft Shredder
Video Overview Gallery Application Features Sepcifications
Video
Overview

Double shaft shredder is controlled by an intelligent and innovative PLC. In case the industrial shredder machine is overloaded or foreign objects are in the cutting unit, the rotor stops and moves backward (return overload behaviour and reverse running to prevent overfeeding and protect against damage from foreign objects). The precisely serrated fixed knives make sure the material is shredded with a minimum of power. The fastened wiper element helps to avoid multiple turn coiling and raising of the material to be chopped.

Double Shaft Shredder Double Shaft Shredder raw-material-output
Gallery
Double Shaft ShredderDouble Shaft ShredderDouble Shaft ShredderDouble Shaft Shredder

Suitable Materials:

1.Metal: aluminum can bundle, steel drum, car shell, color steel tile, bicycle, copper aluminum radiator, oil filter, scrap wires, cables, aluminum composite plastic panel, steel wire rope, gas tank, iron scrap, zip-top can, engine case, paint bucket, etc.

2.Plastic: plastic pallet, plastic drum, plastic bucket, plastic film, waste appliances shell,garbage plastic drum, IBC drum, IBC barrel, garbage bag, rubbish bag, plastic pipe, washing machine, forklift pallet, lead acid battery shell, etc.

3.Textile: scrap clothes, shoes, fishing net, woven bag, ton bag, jumbo bag, fishing net bundles, dust collector bag, industrial textile waste, etc.

4.Wood: wood mattress, wood furniture, wood pallet, scrap timber, sawdust chipboard composite board, wooden door, forklift pallet, wood board, wood template, wooden case wooden box, wood sofa, wood bed,etc.

5.Paper: scrap paper and cartons, including scrap books, carton board, carton box. packaging box, waste newspaper, office paper, printing paper, paperboard, etc.

6.Waste household appliances: TV, washing machine, refrigerator shell etc.

7.Pipes: large pipes, pipe fittings, PE pipes etc.

Scrap tires: car tires, truck tires etc.

9.All kinds of Kitchen waste, domestic waste, rdf derivatives, medical waste,garden waste etc.

Features

1.Blade materials include 9CrSi, Cr12MoV, SKD-II, D2, DC53, etc. It also can be customized.

2.Steel plate of crushing chamber is very thick, so very strong and durable, long service life.

3.We design shredder machine blades with different thickness for processing different raw materials.

4.The bearing pedestal adopts the split type, easy to maintain and replace the blade.

Sepcifications
Model Motor Power (Kw) Capacity (T/H) Blade Number (Pieces) Feed Hopper Size (mm)
ZY-D800 22*2 1-1.5 20 800*1200
ZY-D1000 30*2 1.5-2 34 1000*1500
ZY-D1200 45*2 3-4 24 1500*2000
ZY-D1500 55*2 4-5 20 2000*2500
ZY-D2000 110*2 10-15 20 2500*3000
